Frame | Tectonic T2, aluminum, 29 " cross country geometry, internal cable routing, 9 mm x 141 mm QR dropout convertible to 12 mm x 148 mm thru axle, replaceable hanger, tapered headtube |
Fork | SR Suntour XCM, 29 ", steel steerer, hydraulic lockout, 9 mm x 100 mm, QR, 100 mm travel |
Cranks | Prowheel Charm, aluminum, 30T |
Pedals | Mongoose, nylon |
Derailleur | Shimano SLXRD-M7000 |
Sorting | Shimano SLX SL-M7000, 12-speed |
Cassette | Sunrace, 12-speed, 11-50T |
Chain | KMC X11 |
Rims | WTB ST-i29, aluminum double wall, 29 mm ID, 32H, tubeless compatible |
Coats | Kenda Kadre, 29 in x 2.20 in, wire bead |
Ammunition | Xposure, aluminum, ball bearing, 9 mm x 100 mm, 32H, 6-boltXposure, aluminum, ball bearing, 9 mm x 141 mm QR,32H, 6-bolt |
Wires | 14G, stainless steel |
Brakes | Tektro HD-M290, hydraulic, aluminum, 160 mm rotor |
Handlebars | Xposure, double-butted aluminum, 740 mm width, 15 mm rise, 31.8 mm clamp |
Stem | Xposure 3D forged aluminum, threadless, 60 mm / 70 mm, 6 °, 31.8 mm clamp |
Grips | Xposure Kraton, semi-ergo lock on |
Head composition | Threadless,ZS44 / ZS56, retainer bearing |
Seat | Mongoose MTB, steel rails |
Seatpost | Xposure, aluminum, 350 mm, zero offset, 31.6 mm |
Platform | TYAX |
Year of studies | 2021 |
