Nothing is Impassable The best dual-suspension gravel bike for rugged dirt roads and singletrack trails. With the Kingpin system and Lefty fork, nothing is off-limits. Where it thrives Gravel and Dirt Roads, Rough Pavement, Trails What it's built forGravel riding, back road exploring, bike packing and off-road adventuresHighlights• Lightweight Topstone Carbon frameset with Kingpin suspension / SmartSense Light equipped •Shimano GRX 800 11-speed gravel group / SAVE Carbon seatpost •WTB KOM Light rims w/ 700x45c WTB Riddler TCS Light tires Go ahead, ride it. If your idea of a fun road ridestarts where the pavement ends, no other gravel bike can take you further than the dual-suspension Topstone Carbon. Its revolutionary Kingpin system and Lefty Oliver gravel fork offer traction, comfort and control beyond the dreams of other drop-bar bikes, on everything from beat-up backroads to full-tilt singletrack. Get in deep, come out smiling. Kingpin Suspension Delivering a smooth ride without the added weight and complexity of a shock and links, Kingpin is our answer for the most demanding gravel riders. Whether you need more comfort to go long, more traction to push beyond or more giveto take on the tech - Kingpin is the maintenance-free, lightweight answer to your prayers. Ride Brilliantly On every ride, SmartSense has your back. SmartSense's system of intelligent lights (and optional rear-facing radar) increases your visibility out on the open road and makes it easy to ride smart. Load Up. Roll Out. With plenty of gear and waterbottle mounts on the frame and fork, Topstone Carbon is ready to load up and go long. Corner like a BossRail through the rough and come out smiling. Led by our OutFront steering geometry, the Topstone Carbon offers up handling that's serenely stablein the chop, and light & nimble everywhere else.
Frame | Topstone Carbon, Kingpin suspension system, SmartSense equipped, 12x142mm thru-axle, 27.2 dropper post ready, BSA 68mm threaded BB, DirectLine internal cable routing, removable fender bridge, multiple gear/bottle mounts |
Fork | Topstone Carbon, 1-1/8" to 1.5" steerer, 55mm OutFront offset, flat mount disc, internal routing, 12x100 thru-axle, triple bottle/gear mounts, fender mounts |
Cranks | Shimano GRX 800, 48/31 |
CentralIngredients | Shimano BSA 68 |
Derailleur | Shimano GRX 800, braze-on |
Derailleur | Shimano GRX 81, Shadow RD+ |
Sorting | Shimano GRX 800, 11-speed |
Cassette | Shimano HG800, 11-34, 11-speed |
Chain | Shimano HG701, 11-speed |
Rims | WTB KOM Light i23 TCS, 700c, 28h, tubeless ready |
Coats | WTB Riddler TCS Light, 700 x 45c, tubeless ready |
Bullets | (F) Formula cartridge bearing, 12x100mm, centerlock / (R)Formula cartridge bearing, 12x142mm, centerlock |
Wires | Stainless Steel, 14g |
Brakes | Shimano GRX 800 hydraulic disc, 160/160mm MT800 rotors |
Brake levers | Shimano GRX 800 hydraulic disc |
Handlebars | Cannondale 2 ShortDrop, 7050 alloy, 12 deg flare drop |
Stem | Cannondale 2, 6061 Alloy, 31.8, 7° |
Flu | Fizik Solocush Soft, 3mm |
Head composition | Integrated, Carbon, 1-1/8" - 1-1/2" |
Seat | PhysicsTerra Argo X5, S-alloy rails |
Seat post | SAVE Carbon SmartSense, 27.2, 350mm (XS-L), 400mm (XL) |
* | Specifications and prices are subject to change without notice. Product images are for reference only. |
Extra | SmartSense with Lights, StVZO compliant (lights do not blink/flash) |
Year of studies | 2022 |
Platform | TOPSTONE CARBON G2 |
Connectivity | Cannondale Wheel Sensor |
Mass | Wheel weights are not given because there is no uniform oneweighing standard. We always recommend having the bike weighed in the given specification at the store and comparing it with the real weight of bikes from other brands. |
