| Frame | Moterra Neo Carbon Front Triangle, SmartForm C1 Alloy Swingarm, 160mm travel, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH hanger, post mount brake, 1 |
| Silencer | RockShox Deluxe Select+, Coil, 2-Pos mode adjust, adjustable rebound |
| Fork | RockShox Zeb Select +, Charger RC, 170mm, DebonAir, 15x110mm, 44mm offset |
| Engine | Bosch Performance Line CX |
| Control unit | BoschKiox |
| Battery | Bosch PowerTube 750Wh |
| Charger | Bosch 4A |
| Cranks | FSA Bosch E-bike w/ 55mm chainline, 160mm, 34T |
| Derailleur | Shimano XT |
| Sorting | Shimano XT, 12-speed |
| Cassette | Shimano XT, 10-51, 12-speed |
| Chain | Shimano XT, 12-speed |
| Rims | WTB KOM Trail i30 TCS, 32h, tubeless ready |
| Coats | (F) Maxxis Assegai, 29 x 2.6", 3C, EXO+, tubeless ready, (R) Maxxis DHR II, 27.5 x2.6", 3C, EXO+, tubeless ready |
| Bullets | (F) Formula 15x110mm thru-axle / (R) DT Swiss, 12x148mm thru-axle |
| Wires | DT Swiss Champion |
| Brakes | SRAM Code RSC hydraulic disc, 4-piston, CenterLine 220/200mm rotors |
| Brake levers | SRAM Code RSC hydraulic disc |
| Handlebars | HollowGram SAVE riser bar, Carbon, 35mm clamp, 30mm rise, 8° sweep, 5° rise, 780mm |
| Stem | Cannondale 2, 6061 Alloy, 35mm, 0° |
| Flu | FabricFunGuy |
| Head composition | Acros integrated sealed bearing |
| Seat | Fabric Magic Elite Saddle, cro-mo rails |
| Seat post | Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M), 170mm (L-XL) |
| * | Specifications and prices are subject to change without notice. Product images are for reference only. |
| Platform | MOTERRA CARBON LT 29 G2 |
| Mass | The weights of the wheels are not given because there is no uniform weighting standard. We always recommendhave the bike weighed in the given specification at the shop and compare with the real weight of bikes of other brands. |
| Extra | Lezyne Super HB STVZO E1000 w/ remote high beam switch |
