Frame | All-New, 165mm travel, Carbon, Proportional Response Tuned, Guidler idler pulley/chainguide, BSA 73, ISCG05, tapered head tube, AiOffset |
Silencer | Fox Float Factory X2, 205x65 Metric Trunnion, Air, Adjustable High Speed/Low Speed Compression, High Speed/Low Speed Rebound |
Fork | Fox Float Factory 38, 170mm, 15x110mm thru-axle, tapered steerer, 44mm offset |
Cranks | SRAM X1 Eagle B148 CL55, 30T |
Center composition | SRAM DUB BSA MTB73 |
Front derailleur | ON |
Derailleur | SRAM GXEagle Lunar |
Sorting | SRAM GX Eagle, 12-speed |
Cartridge | SRAM XG-1275, GX Eagle, 10-52, 12-speed |
Chain | SRAM NX Eagle, 12-speed |
Rims | WTB KOM Trail i30 TCS, 32h, tubeless ready |
Tires | (F) Maxxis Assegai, 29 x 2.5", Dual compound, EXO+ puncture protection, tubeless ready (R) Maxxis Minion DHR II, 29 x 2.4", EXO+, tubeless ready |
Hubs | (F)Formula, 15x110mm thru-axle / (R) SRAM MTH 700, 12x148mm, XD Driver |
Wires | DT Swiss Factory J-Bend |
Brakes | SRAM Code RSC hydraulic disc, 220/200mm CenterLine rotors |
Brake levers | SRAM Code RSC hydraulic disc |
Handlebars | Cannondale 1 Riser, Carbon, 30mm rise, 8° sweep, 5° rise, 780mm |
Stem | FSA Grid 35, 35mm |
Grips | FabricFunguy |
Head composition | Integrated Sealed Bearing, Tapered |
Seat | Fabric Scoop Shallow Elite, hollow cro-mo rails |
Seatpost | Cannondale DownLow Dropper w/ Matchmaker lever, 31.6, 125mm (S), 150mm (M), 170mm (L-XL) |
* | Specifications and prices are subject to change without notice. Product images are for illustrative purposes only. |
Extras | Jekyll CustomFender |
Vintage | 2022 |
Platform | JEKYLL 29 G1 |
Weight | Wheel weights are not given because there is no uniform weighing standard. We always recommend having your bike weighed to the specified specification at a store and comparing it to the real weight of other brands of bikes. |
